Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 230

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 230
7. Wasseralfingen. 580. Ostermundigen Loco-motive. 581, 582. WasseralfingenRailway. … 583. FARE-RECORDINGREGISTER. Complete withtotal index, trip sign, and bell.Face removed to show themechanism. The key at the right returnsthe trip index to its normalzero, and also sets the upand down index to its slotin the face. The total index isa continuous register and can-not be tampered…

Mechanical movements
