Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 246

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 246
rtical shaft F can be driven ineither direction by means of the bevel gears and clutch on shaft B, theclutch being moved by a lever. 629. Plan of intermediate gears and spring pin. 630. VARIABLE DRIVE MOTION. Two cone pulleys mountedwith differential spur gear on the driving shaft with a cross arm… … 630A. VARIABLE SPEEDGEAR. The method illustratedpermits of securing variable speedsbetween two shafts which divergefrom a common center in a simpleway. A group of three level gears 242 GEARING AND GEAR MOTION, ETC. are mounted on one shaft, a slidable spur pinion is mounted on theother shaft that…

Mechanical movements
