Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 252

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 252
642. TURNING A SQUARE BYCIRCULAR MOTION. A device onehundred and fifty years old. Not an eco-nomical device for square work, but ap-plicable for irregular and fluted work. Pos-sibly the original idea of the rose lathe. 643. DOUBLE-LINK UNIVERSAL JOINT. This arrangement allows of a large deviating… … 248 MOTION AND CONTROLLING DEVICES, ETC.

Mechanical movements
