Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 254

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 254
MOTION AND CONTROLLING DEVICES, ETC. 249 … 648. RECIPROCATING MOTION with a stop at each stroke from uniformcrank motion. The crank pin follows theopposite curves in slot at each half revo-lution. Rebounding at the wide part ofthe slots is opposed by buffer springs. 649. RECIPROCATING INTO ROTARYMOTION WITHOUT DEAD CENTERS. The cross-head…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
