Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 252

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 252
MOTION AND CONTROLLING DEVICES, ETC. 249 … SacJsiiS^^ 648. RECIPROCATING MOTIONwith a stop at each stroke from uniformcrank motion. The crank pin follows theopposite curves in slot at each half revo-« lution. Rebounding at the wide part ofthe slots is opposed by buffer springs. 649. RECIPROCATING INTO ROTARYMOTION WITHOUT DEAD CENTERS.The…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
