Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 254

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 254
648. RECIPROCATING MOTION with a stop at each stroke from uniformcrank motion. The crank pin follows theopposite curves in slot at each half revo-lution. Rebounding at the wide part ofthe slots is opposed by buffer springs. 649. RECIPROCATING INTO ROTARYMOTION WITHOUT DEAD CENTERS. The cross-head… … 650. RIGHT-ANGLECOUPLING for revolving shafting. A, driving shaft and crank.B, driven shaft crank. C,point of intersection of shaftcenters. D, driving crankpin, pointing to the center C.E, connecting arm. F, oscil-lating piece with pins point-ing to the center C. G, con-necting arm to crank pin…

Mechanical movements
