Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 80

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 80
225. TRUNK ENGINE.—Does away with theslides and cross-head. It is also used for compoundingby using the initial pressure at the trunk end and ex-panding beneath the piston. STEAM POWER. 69 226. OSCILLATING ENGINE, with trunnions onmiddle of cylinder. … 227. COMPOUND OSCILLATINGENGINE.—Cylinders at right angles. 22S. TWIN-SCREW OSCILLAT-ING ENGINE.—A through piston rodconnects directly to crank-pins on theshaft face plates. Suitable for small boats. 229. OSCILLATING HOIST-ING ENGINE.—The piston rodsare attached to an eccentric strap;one fixed, the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
