Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 256

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 256
654. FRICTION-PLATECLUTCH. In this model theplates are pressed into V-shapedrings with perforations for lubrica-tion. The V shape allows of agreat friction with light pressure onthe clutch lever. Alternate V plates are fixed toouter shell by their mortised edges,and the intervening plates to… … 656. FRICTION CLUTCH, ferowntype. The usual sliding sleeve on theshaft and connection to an arm on aright and left double-thread screw, whichexpands the friction blocks and so clutchesthe inner face of the pulley rim.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
