are alsob b, by the pieces cccc. Yokesdd connect these with a crank e onthe main shaft of the trunk. Steamis admitted through the valve / tothe central space g, which serves asa steam chest. The arrangementof the ports is shown at i. Thedrum is mounted on trunnions,through one of which the…
