Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 298

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 298
765. EYE-BENDING MA-CHINE. A hand-operated ma-chine which grips the end of thewire against the central pin by theupper lever, when the lower lever isswung around against the stop andthen forming the reverse bend bythe treadle and push bar. … 766. ANGLE IRON BEND-ING MACHINE. The lever, with adjustable jaws and slidinggauge, swings on a pivot and bearsagainst a block. A set piececlamped upon the sector limits thebending angle. 294 MILL AND FACTORY APPLIANCES AND TOOLS, ETC.
