Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 381
1535. DOG-POWER MACHINE.—The plane of the track wheel is setat an angle of about 20 = , with itsunder edge bearing upon a frictionpulley. Shaft and fly-wheel, withcrank for operating churm … 1536. GEARED HORSI^POWER.—The sweep carries the pinion and spurgear on the second shaft around thestationary spur gear, rotating the centralshaft and pulley at high speed. DJ/
Mechanical movements
