Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 308

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 308
ring, so as to produce any desired graduation in the strength ofblow of the chisel, d, is brought about by increasing or diminishing theeffective radius of the cam to increase or diminution in the height of liftof the ram h. The cam is made tapering in the direction of its axis andis mounted upon… … ::jl mili and factory appliances and tools, etc. S02. DOVETAIL:

Mechanical movements
