18. GEARED I BEAML TROLLEY. Designed for mov-11 ing heavy articles on overhead I|F beam railways in factories. Thetrolley wheels are geared to a driv-ing shaft with sprocket wheel andchain, the lift being an ordinarytackle, not shown. … 19. VARIABLE POWER AND SPEED with friction cone pulleys andtraversing pulley as applied to a drillingmachine. The transmitting roller ispivoted in a frame that slides on a sidebar and is clamped by a screw at theposition required for the desired speed.See No. 106, 1st vol., for a frictionlessform…
