Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 354

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 354
MISCELLANEOUS DEVICES. 349 As shown, each type arm is connected by an adjustable steel wireconnector with the key lever pivoted at the back of the machine andprojecting beyond the front, where it is curved upwardly and providedwith a finger piece or key bearing the character or characters… … 895. REMINGTON TYPEWRITER. The end of the type armand the double type carried thereby is shown in detail at A, and the paper-supporting roller, B, isshown in full linesabove the lower-casetype, and in dottedlines in its positionfor writing capitals.The capitalizing key, C, which is the fore-most…

Mechanical movements
