Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 360

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 360
machines wherein the article to be wrapped and the wrapperis inserted in a pocket disposed upon the periphery of a carrying wheelwhich as it moves brings the article and its wrapper under the actionof various instrumentalities whereby paper or other wrapping materialis folded down on the article.… … with it as to wrap it on three sides, the ends of the paper projecting outfrom the pocket. The rotation of the carrier then brings the pocketbeneath a folding fmger which as the wheel stops is moved to bend downone of the projecting sides of the paper wrapper forward upon the arti-cle, thus forming…

Mechanical movements
