Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 65

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 65
and lower furnace for obtaining aperfect circulation in the grate. 95. Longitudinal section of furnace. 6o GENERATION OF POWER, STEAM. 96. ANNULAR STEAM BLOW-ER. For boiler and other furnaces. Anannular cast-iron chamber perforated forsteam jets at an angle that projects thejets in a converging…
