Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 73

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 73
6S GENERATION OF POWER, STEAM. … 131. CENTRIFUGAL STEAM SEPARATOR. The centrifugal force produced by the steam whirlingaround the spiral partitions causes the entrained waterto be thrown against the outer shell to drip to the bot-tom of the case. BOILER STEAM CONNECTION 132. LOW WATER ALARM. Bundy type. For steam boilers.…
