Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 86

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 86
By-passValve … The cylinders are separated somewhat and have a sleeve betweenthe heads, which is bolted to the front head of low-pressure cylinder.At the front it is held by a flange which makes a joint around it. Thisallows easy inspection and repair of low-pressure piston, as the sleevein question slides into…

Mechanical movements
