Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 315
BY-PASS VALVEM BY-PASSVALVE HIGH PRESSURE STEAM Figure 145 Testing Low-Pressure Cylinder Packing. Engine on top quarter. Starting valve S open, as in Fig. 145. Reverse lever in back motion. This allows steam to flow through starting valve into low-pressure steam COMPOUND LOCOMOTIVES 309 chest P,…
Locomotives
