Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 94

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 94
188. CORLISS VALVE GEAR. In thisdesign, B is the bell crank, which carries thehook H mounted on a short shaft, on theother end of which is the trip lever (not shown),which engages with the knock-off cam C, oper-ated by the governor rod. K is the drop leverwith dashpot connection. The cam lever…

Mechanical movements
