actuatesthe star wheel D,and the segment Cthe star wheel E.In the star wheelsadjustable studs D^and El are fixedon which the connecting rods F and G are pivoted.The other end of these rods form the fulcra of the swinglever H at the points J and K, the boxes being sup-ported on the box rod L,… … Fig. 35. 134 TAPPET AND DOBBY LOOMS The traverse of the stud in combination with theleverage of H, whicli now has its fulcrum at point K,is such as to lift the second box to the level of therace. To raise the third box, the star wheel E beingin its former position, the segment B is moved toengage…
