Babbit, Arthur B · New York, H. Holt and company · leaf 41
ATE 2 Make drawings of the geometrical figures givenin one of the rectangles shown on page 30. Therectangle shown in the copy represents the marginlines. Keep the pencil sharp^ using the conical point forlocating points and the chisel point for drawing lines.Make very light, fine lines. Do not put… … Plate 2 CHAPTER VI WORKING DRAWINGS PLATES 3 AND 4 If we look at an object through a transparent planeand trace the outline as seen upon that plane, theresult is a perspective drawing of the object. Therelation of the object to the plane determines thecharacter of the drawing, and as the observer…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
