Babbitt, Arthur B. (Arthur Bradford), b. 1873 · New York, H. Holt and company · leaf 155
HANICAL DRAWING line of the cutting plane is given and the section drawnin another place. This is illustrated in Fig. 54. Inthis figure the lines A B and C D represent the linesof two cutting planes, and the figures below the draw-ing show the shapes of the sections. It is necessaryto distinguish… … PARTIAL SECTIONS 145
Mechanical drawing
Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
