Babbitt, Arthur B. (Arthur Bradford), b. 1873 · New York, H. Holt and company · leaf 184
nce. C K D, Fig. 87, is a semicircumference. A chord is a straight hne joining the extremities> of an arc. See hne E H, Fig. 87. A tangent is a straightline which touches the cir-cumference of a circle butdoes not intersect it, asM N, Fig. 87. The pointat which the tangenttouches the circle is… … Fig. 88 174 MECHANICAL DRAWING one-half the circle is called a semicircle. See R V T O,Fig. 88. A sector is the area bounded by two radii and thearc which they meet. See Fig. 88. When the radiiare perpendicular, the sector equals one-fourth ofa circle and is called a quadrant. See R 0 Y, Fig. 88.…
Mechanical drawing
Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
