circle—From the given pointA draw a line to the centerof the circle. Find pointB by bisecting the line A C.(Problem 1.) With B asa center and radius B A,draw semicircle 1, intersect-ing the circle at D. Theline DA will be tangent tothe circle at D. Note.—If from any point onthe arc of a semicircle…
