Fig J 4 … WORKING DRAWINGS 33 lustrated the two principles by which the perspectivedrawing and the working drawing views are ob-tained. Note that in Fig. 14 none of the hnes areseen on the picture plane in their true length, beingforeshortened because of the converging lines ofsight, while in Fig. 15 all the…
