Fig. 220, Eolling a Cone to Obtain the Development of Its Surface Required: To draw a pattern for one of the objects shownin Fig. 222 or 223, or any similar object as assigned by theinstructor. Instructions: Draw the orthographic views and make a con-struction for the pattern similar to that shown… … Fig. 221. Type Problem. Pail
Mechanical drawing
