Fig. 267. Library Table ADVANCED DRAWING 239 of furniture construction. In ordei to cover this field as thor-oughly as possible, two type problems of widely different char-acter are presented. Figs. 263 and 264. The student should fix Ct-ossbar ^ ^ Woade» P/n … 1% i_ Z/o/nf and Cornef af Q Fig. 268. Morris Chair in mind the correct proportion of the joints used in these prob-lems as well as their names and uses by referring to the discussionaiui figures on pages 231, 232, and 233. 240 MECHANICAL DRAWING DATA FOR DRAWING PLATE 35 Given: The perspective…
