Mechanical drawing for secondary schools (1916)

Crawshaw, Fred D. (Fred Duane), b. 1874, Phillips, J. D. (James David), 1869- joint author · Chicago, New York, Scott, Foresman and company · leaf 319

An illustration from Mechanical drawing for secondary schools, 1916, leaf 319
the faces of the cube.Fig. 345. 4. Draw the curves by the method given under, IsometricCircles. 314 MECHANICAL DRAWING Cabinet Drawing PREPARATORY INSTRUCTIONS FOR DRAWING PLATE 54 Cabinet Drawing is similar to isometric in that measurementsare made parallel to three axes. One of the axes is… … Fig. 355. Cabinet Drawing of Cube

Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
