t first; then the side and top views. Fig. ]6. Front, top, and right side views of a circular plinth, or oftablets arranged in the form of a plinth, supporting a square plinth, ortablets arranged in the form of a plinth. Draw the top view of the circular plinth first; then the front and sideviews.…
