Detroit. Public schools. Dept. of instruction, teacher training and research. [from old catalog], Kepler, Frank Roy. [from old catalog] · Detroit · leaf 15
ojections onthe horizontal and vertical planes respectively. If the pointA remain fixed and the line be revolved until it is parallel toV the point B will move to M, in an arc, the plane of which isparallel to H. The projection of this arc on H is bm and on Vis the Une bm. The horizontal projection…
Projection
