138 MECHANICAL DRAWING, PLATE XII. Fig. 98. Top^ fronts and left side views of a vertical cone intersectedby a plane at an angle with its base and cutting all the elementsj the realshape of the sectionj also the develop?nent of the lateral surface of thecone. The points in which the contour…
