COUPLING BOLT … EXPANSION BOLT TAPERED BOLT Machinery Fig. 10. Various Forms of Bolts meaning of the term, is that nuts are used on bolts whereasscrews are inserted into tapped holes; there are exceptions,however, to this general classification. When a bolt is usedto connect two pieces, a hole is drilled through…
