Mechanical drawing; a treatise on the drawing of mechanical and machine details (1920)
Jones, Franklin Day, 1879-1967 · New York, The Industrial press; [etc., etc.] · leaf 258
Machinery Fig. 6. A Cylindrical or Barrel Cam that the distance, as measured along any line intersecting thecamshaft axis, will be the same at all points; furthermore, thecurve of this remaining half, which represents the path ofthe follower roller, should not be nearer the camshaft axisthan the…
Mechanical drawing
