Mechanical drawing; a treatise on the drawing of mechanical and machine details (1920)

Jones, Franklin Day, 1879-1967 · New York, The Industrial press; [etc., etc.] · leaf 344

An illustration from Mechanical drawing; a treatise on the drawing of mechanical and machine details, 1920, leaf 344
at surface of the glass plate, the edge of which isrepresented by line A A, point C would be located at D on thedrawing, point F, at G, point H, at 7, etc. When actuallymaking a perspective drawing, since the latter is in the sameplane as the plan view, these points, such as D, I, and G, arefirst… … 332 MECHANICAL DRAWING is placed at any desired angle. In this case side JF in theplan view is located at 30 degrees from line A A, so that theperspective drawing will show the side and end surfaces.The line A A is drawn close to the plan view, because if thisline were considerably below the plan…

Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
