Mechanical drawing for industrial and high schools (1917)
Leeds, Charles Carley, 1870- [from old catalog] · New York, D. Van Nostrand company · leaf 36
likehhood of the views beingfinished incorrectly. Do this work neatly, showing all the necessary hidden surfacelines and placing on all dimensions as shown, but keep clearly inmind the thought that the important feature is to use this workas an aid in obtaining a thorough grasp of the principles of… … Fig. I
Mechanical drawing
