the pjTamid. Now connect the apex point withthe comers on the base and the figure is complete. To emphasize the convenience of these related axes, the student is reminded that measurements may oe made onlv on isometriclines, and as the lines forming the outline of the pjTamid base arenot at right… … FlG. 20. ical \-iew of the side of the piece is di\-ided into a certain nimiberof parts (any nmnber), spaced either evenly or unevenly, thenthese lines or axes are used as shown when constructing the iso-metric A^iew. Two appHcations are shown, one of which is pleasingto the eye, and the other…
