Lathing. All stud walls, partitions and ceilings or first story are to belathed with No. 1 pine, spruce or yellow poplar lath, free fromred knots or bark, and well seasoned; break joints at leastevery 18. Place lath § on the ceilings and but very littlecloser on the stud walls. No lathing through… … -*~^Jy rut.. Mitv-.A-s.ju. rw,™*--., i.l.tb/iw,. fc) •r Fig. 252.Residence for G. W. Wilson, Champaign, 111. Brown Brothers, Architects, No. 808-9Security Savings Bank Bldg., Cedar Rapids, Iowa. ARCHITECTURAL DESIGN 187 Plastering. Plaster all interior wood lath with Adamant patent wallplaster (or…
