whose outside diameter is nearest to theoutside diameter of the nut. The lock-nuts are screwed intoposition by means of a spanner wrench having projectingpieces which fit into the recesses shown in end elevation.The taper of the conical bushes may be made j- in 12 onthe diameter. The faces marked… … 270 MECHANICAL DRAWING. Stuarts Clamp Coupling.—This coupling, shown in Fig.355, differs from the Sellers coupling in having tapered
