Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 35
hemselvesreadily to our readers, we would advisethem to refer back to what we had tosay on projection. We have brought itup at this point in order that our read-ers may get the idea somewhat in theirminds, but shall take it up more thor-oughly at a later point in this book.In the same way that the… … Another Correct and Incorrect method ofDrawing for Fittings. the stack A. Therefore in the elevation,locate it at the same distance to theright of the stack as shown on page 31. MECHANICAL DRAWING FOR PLUMBERS The plans and elevations of any pieceof work must always be consistent.Otherwise, they…
Plumbing · Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
