any other. For. the different views of these fixtures, andwould advise practice in constructingthem, first, on the same scale that weshow, and then on a larger scale, as it isof course necessary to be able to drawwork in any size, and not well to practicecontinually on the size which we give inthe… … Showing: a Scale of 1 -8 inch to 4 inches, same as in Fig. 42. some reason or other, the washout watercloset shown in Fig. 46, often appears inplumbing drawings. While saying noth-ing as to the excellence of this particulartype, or otherwise, it is.a difficult matterfor the beginner in drawing to…
