D OTJBl-.E. H. 0\J SE. 72 MECHANICAL DRAWING FOR PLUMBERS TE?_oo- … Fig. 81 .—Elevation of Double House. plan, Fig. 78, the main drain andbranches and risers with their respectivesizes can he found. From Fig. 81, whichshows the elevation of the house, can befound the total height of the building,the distance between floors, the pitch ofthe roof, etc. Thus far, such…
