arts of this work in the nextchapter. CHAPTER XVII IN Fig. 84 of this article is shown theelevation of the bath room workas located in the second floor planof double house (Fig. 80) of thepreceding chapter. This view is taken looking in the direc-tion in which the arrow B points in Fig.80. Any… … C_lla_r Wa.1l Fig. 85. The only disadvantage In viewing thework as we have, is that the bath roomfixtures on the other side of the housecome directly behind those shown in ourdrawing, and therefore cannot be repre-sented. In this case, however, it is notessential that more than one of the twosets…
