Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 88
bathroom fixtures on the secondfloor. Show on this work, roof connec-tions and increase of size of stack wherenecessary, also connection of main ventinto stack if the work is to be so con-structed. Also show the work at thefront cellar wall clearly. We would ad-vise including the wash trays and… … Fi^.lZ YlRST YlOOR P-L.iVSSL
Plumbing · Mechanical drawing
