Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 90
. For instance, in the elevation shownby Fig. 105, in the main lines of ventpipe serving the fixtures connecting intostacks C and D, appear behind thesestacks, and as the main vents in these zontal branches in the Cellar, Which con-nect into the main line for soil pipe.In Fig. 105 we get simply the… … two cases are the same size as the stacks not show to the best advantage in Fig. they cannot be seen. To get around this 105, and neither does the offset on point we have shown these two lines a stack A. little to one side of the stacks. This is The two bath rooms probably show to not strictly…
Plumbing · Mechanical drawing
