PROJECTIONS. 85 In Fig. 21 the faces are perpendicular to V only (except thefront end, which must be light), hence the triangle can only beused in elevation. 70. Prob. 9. To draw the two projections of a right cylin-der standing on its base. Fig. 22. Its horizontal projection will be a circle equal…
