Mechanical drawing for industrial and high schools (1915)
Leeds, Charles Carley, 1870- · New York, D. Van Nostrand company · leaf 52
2nd. Horizontal lines Dimension lines 4th. Angular lines. Projection lines … CThoper 1> 5fh. Projection and Dimension lines— Dimensions— NotesFig. 14. left side, rule in all the vertical outlines; and, finally, rule in theangular outlines. Now, adjusting the pen to a much finer line, rule in the pro-jection lines; these lines for drawings of small figures should…
Mechanical drawing
