EXAMPLES IN ENGINE WORK. 287 gravity into the groove in the crank wheel, and is car-ried by centrifugal force to the outside surface of thecrank-pin ; so that whatever other means of lubricationmay be employed, this one will always be positive inits action. This cut also shows the manner in…
