Mechanical drawing for trade schools (1909)
Leeds, Charles Carley, 1870- [from old catalog] · New York, D. Van Nostrand company · leaf 84
■~T CLASS Indusfrial trade Machinist NAME John W^.Roberts date Jan. 6.08. THE CARNEG/E TECHNICAL SCHOOLS pittsburoh, pa.School of Apprehtices and journeymenmechanical drawing 12 Speed LatheTailstock Details SCALE Full Size owe. no. C_ IOS/ LESSON No. 37. TAILSTOCK ASSEMBLY. —Drawing C-1032 shows…Mechanical drawing
