see Holmes onthe Steam-engine, p. 290. See also Clarks Railway Machinery (1855),Clarks Steam-engine, Zeuners and Auchinclosss Treatises on Slide-valve Gears, and Halseys Locomotive Link Motion. (See page 1095.) The following rules are given by the American Machinist for laying outa link for an… … center of shaft to center of the link-block pin P when the latter standsmidway of its travel. The distance between the centers of the eccentric-rod pins ei 62 should not be less than 21/2 times, and, when space willpermit, three times the throw of the eccentric. By the throw we meantwice the…
